SI4703 FM TUNER EVALUATION BOARD

The VMA444 is a radio and RDS receiver combined with an efficient 150 mW audio amplifier. This module is ideal if you want to create your own clock radio or if you want to add FM functionality to your projects.

Features
worldwide FM band support
digital low-IF receiver
automatic frequency control (AFC)
automatic gain control (AGC)
volume control
RDS/RBDS support
Arduino library available
150 mW amplifier stereo amplifier
level shifters 5 V -3.3V on board
Specifications
interface: I2C
power / logic level: 3.3 - 5 V
sensitivity: 1.7 µ emf
max. output power: 150 mW (8 Ohm)
default gain: 18 dB (8 x) (adjustable)
dimensions: 29 x 22 mm
